Thermostatic Incubator Shaker Vertical

Thermostatic Incubator Shaker Vertical

    • Thermostatic Incubator Shaker Vertical
    • Thermostatic Incubator Shaker Vertical
  • Thermostatic Incubator Shaker Vertical

    Product Details:

    Place of Origin: China
    Brand Name: Hengzi
    Certification: CE
    Model Number: YJYC/YJY

    Payment & Shipping Terms:

    Minimum Order Quantity: 5 units
    Price: Negotiable
    Packaging Details: 1 pcs/CTN
    Delivery Time: 15-30 DAYS
    Payment Terms: T/T
    Supply Ability: 10 UNITS PER 7 DAYS
    Contact Now
    Detailed Product Description
    High Light:

    lab shaker machine


    shaker laboratory equipment

    Structure Characteristics:

    1. USB data system with large storage, automatic data record and store

    2. Wireless U disk data download, instant and automatic

    3. Data downloaded automatically saved as chart and can be printed

      Experiment can be playback by mouse control

    4. With touch screen, multi-process control system for rotating speed, temperature and time along with intermittent control system. Different rotating speed, temperature and time can be set at one time, running mode can be automatically switched in operation

    5. Ultra low speed start, automatic lock when the rotating speed is out of control, adjustable starting speed

    6. Adjustable closed loop heating and cooling system. Silent fan, forced convection and unique air duct make temperature uniformity and fluctuation in high level

    7. Automatic cooling mode which can be switched automatically according to environment temperature

    8. Intelligent cooling and frost-free operation, stable at low temperature for long time operation, Automatic defrost

    9. Time, temperature and rotating speed displayed in one interface

    10. Environment temperature and Monitoring temperature Correction

    11. Rotating Speed Controller with high accuracy; P.I.D. feedback controller, precise and stable, accuracy at ±1rpm

    12. Temperature Controller with high accuracy; P.I.D. feedback controller, accuracy at 0.1℃; Over and under temperature alarm with sound and light( Measured temperature deviated ±3℃ from the set value)

    13. Unique drive system, smooth, stable, reliable and durable

    14. Intelligent alarm system in light and sound with micro processing controller; stop when the door is open, self diagnosis and safety alarm

    15. LCD display with big screen

    16. Parameters auto saving system and automatic start after power interruption

    17. Password lock for operation parameter

    18. Unique motor over temperature alarm and temperature out of control automatic protection device

    19. Scheduled operation and continuous operation, display operation time and remaining time in one interface

    20. Unique slow start

    21. Streamline and large observation windows, ABS cabinet, stainless steel lining and cavity assembly, tilt humanized control pad

    22. With touch screen, time and date can be shown

    23. Optional device: High temperature Shaker(up to 80℃) Humidity Shaker



    Thermostatic Incubator Shaker Vertical

    Model YJYC-1102C YJYC-2102C YJYC-1102 YJYC-2102 YJYC-1112B YJYC-2112B YJYC-1112F YJYC-2112F
    Control Mode P.I.D. Microprocessor
    Convection Mode Forced convection
    Oscillation Mode Rotate Reciprocate
    Display Mode 7 inches touch screen
    Drive Mode Multi-dimensional drive Track drive
    USB Data Download Processing System Yes
    Control System Standard mode; Continuous mode; Process Control mode( multi-process for temperature, time and speed)

    Cyclotron frequency Range


    0;20-300 0;20-280

    Cyclotron frequency Accuracy




    Φ35(customized) 20-250 rpm/min

    Φ50 20-200 rpm/min

    Max Capacity 100ml*60 or 250ml*38 or 500ml*22 or 1000ml*16 100ml*100 or 250ml*56 or 500ml*44 or 1000ml*24 250ml*90 or 500ml*72 or 1000ml*42
    Standard Capacity 250ml*24 250ml*28 500ml*22 250ml*45 500ml*36
    Tray size(mm) 500*360 710*455 950*550
    Timing Range(h) 0-999.9
    Temperature Control Range(℃) RT+5-60 4-60(at 25℃) RT+5-60 4-60(at 25℃) RT+5-60 4-60(at 25℃) RT+5-60 4-60(at 25℃)
    Temperature Accuracy(℃) ±0.1
    Temperature Uniformity(℃) ≤0.3(37℃, working side)
    Temperature Fluctuation(℃) ≤0.1(37℃)
    Number of trays 2

    Outline Dimension

    WxDxH (mm)

    700*580*1320 950*700*1320 1200*800*1630
    Capacity(L) 175 335 580
    Rated Power (W) 600 850 900 1150 1100 1400 1100 1400
    Power AC220±10% 50-60hz
    Environment Temperature Requirement(℃) 5-30
    Additional Function
    1. Ultra low speed start
    2. Adjustable starting speed
    3. Over speed auto-protection
    4. Watchdog timer
    5. Parameter memory
    6. Parameter encryption
    7. Automatic start after power interruption
    8. Refrigerator overload protection
    9. Over and under temperature alarm with sound and light
    10. Stop when the door is open(optional)
    11. Illumination
    12. UV disinfection(optional)
    13. View setting parameters
    14. Monitoring temperature Correction
