Electrothermal Thermostatic Dryer

Electrothermal Thermostatic Dryer

    • Electrothermal Thermostatic Dryer
    • Electrothermal Thermostatic Dryer
    • Electrothermal Thermostatic Dryer
  • Electrothermal Thermostatic Dryer

    Product Details:

    Place of Origin: China
    Brand Name: Hengzi
    Certification: CE
    Model Number: HGZN/HGZN-II

    Payment & Shipping Terms:

    Minimum Order Quantity: 5 units
    Price: Negotiable
    Packaging Details: 1 pca/CTN 20L-43L
    Delivery Time: 15-30 DAYS
    Payment Terms: T/T
    Supply Ability: 10 UNITS PER 7 DAYS
    Contact Now
    Detailed Product Description
    High Light:

    thermostatic drying oven


    high temperature drying oven

    Electrothermal Thermostat Dryer


    Application range:

    This equipment is used for drying, baking and disinfection in industrial and mining enterprises, chemical laboratory, R&D institution, etc.


    Structure Characteristics:

    • Outer Shell Material: Cold-rolled steel sheet surface spray
    • Inner Material: SUS304 Stainless steel
    • Overhead air outlet window

    HGZN: Glass inner door and no Exterior door observation window

    HDPN-II: No Glass inner door and Exterior door observation window

    Microprocessor PID temperature control, accurate and reliable

    Timing range: 0-9999min


    Parameters auto saving system and automatic start after power interruption

    • Inner round cornered design, convenient to clean
    • Shelves adjusted easily and flexiblely

    Optional device:

    Independent external temperature protection device

    HGPN-II: LCD temperature controller

    HGPN-II: LCD temperature conctoller and RS485 Communication serial port

    HGPN-II: LCD temperature controller and Micro pinhole printer

    HGPN-II: RS485 to USB Adapter


    Model Specification:

    Model HGZN-20 HGZN-32







    Teamperature Control Range 50℃-200℃
    Temperature Uniformity ±1℃
    Temperature Fluctuation ≤Max Working Temperature ±3.5%
    Inner Cyclic Mode Natural Convection
    Alarm Type Over temperature alarm and Temperature probe damage alarm
    Work Room Dimension(CM) 26*26*30 30*30*35 40*40*45 50*50*55 60*60*75 35*35*35
    Capacity(L) 20 31 72 137 270 43
    Outline Dimension(CM) 45*44*64 62*47*65 72*57*75 82*67*85 92*77*105 63*54*55
    Shelves 2 2 2 3 3 3
    Rated Power(W) 800 1200

    HGZN: 1600

    HGZN-II: 1000

    2000 3000 850
    Power 1Φ220V 50Hz
